The SINOTRUK HOWO 4×2 Light-Duty Fire Truck is a compact, agile first-response firefighting vehicle built on the reliable HOWO single-axle chassis from China National Heavy Duty Truck Group (SINOTRUK). Adopting 4×2 two-wheel-drive layout, it features small turning radius and excellent passability, perfectly suited for narrow urban lanes, residential compounds, industrial parks, campuses and rural communities where heavy fire engines cannot reach easily.
| Vehicle Type | SINOTRUK HOWO 4×2 Light-Duty Firefighting Truck |
|---|---|
| Drive Type | 4×2 |
| Cabin | HOWO light-duty cabin, with A/C |
| Passenger Capacity | 2–3 persons |
| Engine Model | YUNNEI / YUCHAI (optional) |
| Engine Power | 116–160 HP (depending on configuration) |
| Emission Standard | Euro II |
| Transmission | Manual gearbox |
| Gear Configuration | 6 Forward & 1 Reverse |
| Front Axle Capacity | 2.4 Tons |
| Rear Axle Capacity | 4.2 Tons |
Built on the proven SINOTRUK HOWO 4×2 light-duty chassis, this firefighting truck is a professional first-response emergency vehicle for grassroots fire rescue. It adopts a compact body design and integrated water-foam extinguishing system, designed for rapid disposal of initial small and medium fires. Ideal for narrow urban streets, old residential communities, industrial parks, campuses, scenic spots and township fire stations, it complements heavy-duty fire trucks that fail to enter cramped areas.
| Item | Specification |
|---|---|
| Vehicle Type | SINOTRUK HOWO 4×2 Light-Duty Firefighting Truck |
| Drive Type | 4×2 |
| Cabin | HOWO light-duty cabin, with A/C |
| Passenger Capacity | 2–3 persons |
| Engine Model | YUNNEI / YUCHAI (optional) |
| Engine Power | 116–160 HP (depending on configuration) |
| Emission Standard | Euro II |
| Transmission | Manual gearbox |
| Gear Configuration | 6 Forward & 1 Reverse |
| Front Axle Capacity | 2.4 Tons |
| Rear Axle Capacity | 4.2 Tons |
| Tire Specification | 7.00R16 / 7.50R16 |
| Tire Quantity | 7 pcs including one spare tire |
| Fuel Tank Capacity | 120 L |
| Water Tank Volume | 3000 L (optional) |
| Foam Tank Volume | 1000L |
| Fire Pump | Low-pressure fire pump (CB series or equivalent) |
| Fire Monitor | Manual or optional roof-mounted monitor |
| Max Speed | 90–100 km/h |
| Wheelbase | 3800 mm (optional) |
| Overall Dimension | Approx. 6000–7500 × 2200–2500 × 3000 mm |
| Application | Urban firefighting, community fire rescue, industrial emergency response |
| Standard configuration | Chassis,sub frame, van body,national standard equipment box, 25 units national standard fire-fighting equipment,fire pump(CB10/30 according to the capacity), fire gun(PL24 according to the capacity),fire power take off, sliding gate, row type lights, reel, common tools,rear climbing ladder,water tank. |
| Item | Specification |
|---|---|
| Vehicle Type | SINOTRUK HOWO 4×2 Light-Duty Firefighting Truck |
| Drive Type | 4×2 |
| Cabin | HOWO light-duty cabin, with A/C |
| Passenger Capacity | 2–3 persons |
| Engine Model | YUNNEI / YUCHAI (optional) |
| Engine Power | 116–160 HP (depending on configuration) |
| Emission Standard | Euro II |
| Transmission | Manual gearbox |
| Gear Configuration | 6 Forward & 1 Reverse |
| Front Axle Capacity | 2.4 Tons |
| Rear Axle Capacity | 4.2 Tons |
| Tire Specification | 7.00R16 / 7.50R16 |
| Tire Quantity | 7 pcs including one spare tire |
| Fuel Tank Capacity | 120 L |
| Water Tank Volume | 3000 L (optional) |
| Foam Tank Volume | 1000L |
| Fire Pump | Low-pressure fire pump (CB series or equivalent) |
| Fire Monitor | Manual or optional roof-mounted monitor |
| Max Speed | 90–100 km/h |
| Wheelbase | 3800 mm (optional) |
| Overall Dimension | Approx. 6000–7500 × 2200–2500 × 3000 mm |
| Application | Urban firefighting, community fire rescue, industrial emergency response |
| Standard configuration | Chassis,sub frame, van body,national standard equipment box, 25 units national standard fire-fighting equipment,fire pump(CB10/30 according to the capacity), fire gun(PL24 according to the capacity),fire power take off, sliding gate, row type lights, reel, common tools,rear climbing ladder,water tank. |
1. Excellent Flexible Trafficability
Flexible steering for narrow road rescue.
Stable running on complex road terrain.
Light body for limited road passage.
2. Reliable Integrated Fire Extinguishing Performance
High-efficiency fire pump for fast water intake.
Dual-purpose monitor for multi-type fire fighting.
Anti-corrosion tank for long fire suppression.
3. Humanized Crew & Operational Design
Comfort cab for 5-6 firefighters onboard.
Simple control panel for easy operation.
Warning lights for day & night rescue work.
4. Modular & Durable Vehicle Superstructure
Alloy carriage with anti-rust performance.
Modular cabinet for orderly tool storage.
Reinforced frame for long service lifespan.
5. Low Operation Cost & Global Adaptability
Euro standard engine with low fuel cost.
Global spare parts for low maintenance cost.
Full customization for global fire scenarios.
