3 Axles 40FT Flatbed Semi Trailer

Products Showcases:

● One of the biggest and best truck and trailer manufacturer in China

● 30 years of experience in Special Vehicle

● Build a strict QC team to guarantee the quality

● Fast delivery time

● 12-24 months long guarantee time assurance

Features:

3 Axle 40 Foot Flatbed Semi-Trailer (We use 13-ton or 16-ton FUWA brand axles); the chassis is welded using high-strength low-alloy steel, ensuring a sturdy structure and excellent torsional resistance; it supports multi-leaf steel spring suspension or air suspension, making it ideal for transporting long, narrow goods such as steel, steel coils, timber, and cement boards, as well as bagged cement, machinery, and large-scale cargo.

3-Axle 40-Foot Flatbed Semi-Trailer equipped with a standard 90# tow hitch, compatible with various tractor units; features 12–14 container locks (twist locks) capable of securing a single 40-foot container or two 20-foot containers; tires are 12R22.5 vacuum tires, offering excellent load-bearing capacity and durability. Safety and durability: The braking system is a dual-circuit air brake system with standard ABS anti-lock braking system; the electrical system uses LED taillights and a standard 7-pin connector, ensuring stable and reliable performance.


Applications:

40 FT 3 Axle Flatbed Semi-Trailer common uses are, Container TransportationStandard container sizes are 20 feet and 40 feet, the flatbed truck can load a 40 feet or two 20 feet containers.2.Steel Transportation, including steel plate, steel coil, steel pipe, etc., because the flatbed design is easy to load and fix. It is usually used for medium and long distance transportation between ports, freight stations and logistics parks. Steel transportation includes steel plates, steel coils, steel pipes, etc. Because the flatbed design is easy to load and unload and fix. It can be used with reinforcement equipments such as bundling belt and steel wire rope to ensure the transportation safety.

Performance advantages：

The 3-axle 40-foot flatbed semi-trailer has a strong load-bearing capacity: it can carry more than 30 tons, and some heavy-duty versions can carry up to 45 tons. It is suitable for container transport, bulk cargo transport, and large equipment transport. Simultaneous loading and unloading: the design has no guardrails, allowing for flexible loading and unloading, and is suitable for use with forklifts or cranes.

Specification:

We are a professional manufacturer of various types of vehicles, including tractor trucks, dump trucks, and special-purpose vehicles, Semi-Trailer. Our trucks are very popular in Southeast Asia, the Middle East, Africa, and South America, thanks to their high quality and low prices.

3 Axles 40FT Flatbed Semi Trailer
Tare  Weight		7700kg
Overall  Length		12400mm
Overall  Width		2480mm
Payload		45000kg
SPECIFICATIONS
I Beam & Chassis	Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Middle Flange 6mm,Height 500mm, Bottom Flange 16mm,width 140mm.
Axle	3 axles
	BPW/ FUWA/HJ/L1 Brand 12 ton
Suspension	Heavy duty mechanical suspension
Floor	3mm checker plate
Leaf Spring	13 piece Leaf spring
King Pin	JOST brand 2” Bolt-in King Pin
Landing Gear	JOST brand Two-speed, manual operating, heavy duty landing gear
Wheel Rim	9.0-22.5 wheel rim 13 pieces
Tire	12R22.5 tire with one spare tire. 13 pieces
Twist Lock	12 nos. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container, the retractable central locks can be laid down.
Spare Tire	One set of spare tire including a carrier
Braking System	WABCO RE 4 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Accessories	One standard tool box

Tires:

The 3-Axle 40-Foot Flatbed Semi-Trailer is equipped with 12R22.5 tires, including one spare tire. These tires feature a robust steel-reinforced structure, ensuring exceptional load-bearing capacity and durability. The sturdy tire carcass is designed to withstand high-load operations, making them ideal for long-term heavy-duty transportation. Excellent wear resistance is achieved through a rational tread design and wear-resistant rubber compound, making it suitable for long-distance high-speed or complex mining site road conditions, thereby extending service life. The radial structure reduces heat generation, ensuring safer operation and minimizing the risk of tire blowouts, thus providing excellent heat dissipation properties.
