SINOTRUK HOWO 6X4 Gravel Asphalt Spreader Truck (6 m³ Asphalt Tank and 4 m³ Gravel Tank)

O SINOTRUK HOWO 6X4 Gravel Asphalt Spreader Truck is a specialized road construction vehicle designed for asphalt spraying and gravel spreading operations. Equipped with a 6×4 heavy-duty HOWO chassis, it features reliable driving performance, high spraying precision, and efficient aggregate distribution. The truck is widely used in highway construction, road maintenance, chip sealing, and asphalt pavement projects. Its intelligent control system and uniform spreading technology help improve construction efficiency and road surface quality.

Modelos:

Dimensões gerais (C x L x A) mm9550×2500×3450
Wheel base (mm)3825+1350
Wheel track (front/rear) (mm)2022/1830
Approach/Departure angle(°)16/10
Peso de tara16600
Loading capacity25000
Capacidade de carga dos eixos dianteiros1x9000
Capacidade de carga dos eixos traseiros 2x16000
MarcaSINOTRUK
ModeloWD615.47

Aplicação

O SINOTRUK HOWO 6X4 Gravel Asphalt Spreader Truck delivers excellent road construction performance with high spraying accuracy, stable gravel distribution, and reliable heavy-duty operation. Powered by a strong SINOTRUK diesel engine and equipped with an advanced hydraulic control system, the truck ensures efficient asphalt spraying and uniform gravel spreading for highway sealing and pavement maintenance projects. Its large-capacity asphalt and gravel tanks improve continuous working efficiency, while the intelligent control system provides precise spreading width and spray quantity adjustment. The 6×4 HOWO chassis offers strong load capacity, stable driving performance, and excellent adaptability to various road construction environments.

Especificações:

CabineDriving type 6x4 right hand drive
HW 76 standard cab, with one bed and Air Condition, 70°hydraulically tillable to the front as attached photo for ref.
Dimensões principais do veículoDimensões gerais (C x L x A) mm9550×2500×3450
Wheel base (mm)3825+1350
Wheel track (front/rear) (mm)2022/1830
Approach/Departure angle(°)16/10
Peso em KGSPeso de tara16600
Loading capacity25000
Capacidade de carga dos eixos dianteiros1x9000
Capacidade de carga dos eixos traseiros 2x16000
Max. driving speed(km/h)102
MotorMarcaSINOTRUK
ModeloWD615.47
Tipo4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Cavalos de potência (HP)371
Padrão de emissãoEuro Ⅱ
Caixa de câmbioHW19710, 10 marchas à frente e 2 marchas à ré
EmbreagemEmbreagem de diafragma reforçada, diâmetro de 430 mm
Steering GearBosch brand, power steering, hydraulic steering with power assistance
Tanque de combustível (L)400
Pneu12.00R20 tubeless tyre 7 pcs including one spare tire
BrakesService brake: dual circuit compressed air brake
Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust brake
Capacidade6 m³ tank for gravel and 10 m³ tank for asphalt
Hydraulic systemProportional valve , automatic reversing valve and overflow valve, asphalt pump hydraulic drive motor, hydraulic pump or engine power take-off
Control systemIntelligent computer control in cabin.
PerformanceThe maximum sprinkling width is 3.75 meters, asphalt sprinkling amount: 0.25-4.0 L/㎡, gravel sprinkling amount: adjustable
Spraying mediumemulsified asphalt, hot asphalt, modified asphalt
CabineDriving type 6x4 right hand drive
HW 76 standard cab, with one bed and Air Condition, 70°hydraulically tillable to the front as attached photo for ref.
Dimensões principais do veículoDimensões gerais (C x L x A) mm9550×2500×3450
Wheel base (mm)3825+1350
Wheel track (front/rear) (mm)2022/1830
Approach/Departure angle(°)16/10
Peso em KGSPeso de tara16600
Loading capacity25000
Capacidade de carga dos eixos dianteiros1x9000
Capacidade de carga dos eixos traseiros 2x16000
Max. driving speed(km/h)102
MotorMarcaSINOTRUK
ModeloWD615.47
Tipo4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Cavalos de potência (HP)371
Padrão de emissãoEuro Ⅱ
Caixa de câmbioHW19710, 10 marchas à frente e 2 marchas à ré
EmbreagemEmbreagem de diafragma reforçada, diâmetro de 430 mm
Steering GearBosch brand, power steering, hydraulic steering with power assistance
Tanque de combustível (L)400
Pneu12.00R20 tubeless tyre 7 pcs including one spare tire
BrakesService brake: dual circuit compressed air brake
Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust brake
Capacidade6 m³ tank for gravel and 10 m³ tank for asphalt
Hydraulic systemProportional valve , automatic reversing valve and overflow valve, asphalt pump hydraulic drive motor, hydraulic pump or engine power take-off
Control systemIntelligent computer control in cabin.
PerformanceThe maximum sprinkling width is 3.75 meters, asphalt sprinkling amount: 0.25-4.0 L/㎡, gravel sprinkling amount: adjustable
Spraying mediumemulsified asphalt, hot asphalt, modified asphalt

Característica:

1. Dual-Function Spreading System
Combines asphalt spraying and gravel spreading in one vehicle.
Improves road construction efficiency and reduces equipment cost.
Suitable for chip seal and road surface treatment operations.

2. Large Capacity Tank and Hopper
Equipped with asphalt tank and gravel hopper for continuous operation.
Reduces material refilling frequency and improves productivity.
Suitable for long-distance road construction projects.

3. Reliable HOWO 6×4 Heavy-Duty Chassis
Durable HOWO chassis with strong load-bearing capacity.
Stable driving performance under heavy-load working conditions.
Suitable for construction sites and rough road environments.
