SGZ
SINOTRUK
DIMENSIONS | ||
Tare Weight | 12300kg | |
Overall Length | 11000mm | |
Overall Width | 2490mm | |
SPECIFICATION | ||
Chassis | Skeletal Chassis with special designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Middle Flange 6mm,height 500mm; Bottom Flange 16mm,width 140mm. | |
Axle | 3 axles of Germany design 13 ton | |
Brand Name: BPW/FUWA | ||
Suspension | Germany design heavy duty mechanical suspension | |
Leaf Spring | 13 pieces leaf spring | |
King Pin | JOST brand 3.5” Bolt-in King Pin | |
Landing Gear | JOST brand Two-speed, manual operating, heavy duty landing gear | |
Wheel Rim | 9.0-22.5 wheel rim | |
Tyre | 12R22.5 tubeless tire, in total 13 PCS including one spare tire; 12.00R20/315/80R22.5 are optional | |
Spare Tire | One set of spare tire including 1 carriers | |
Braking System | WABCO RE4 relay valve; T30/30+T30 Spring brake chamber; 40L air tanks | |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint | |
Accessories | One standard tool box | |
Tank and Key accessary | ||
Capacity | 16CBM | |
Engine | American brand Cummins | |
Hydraulic Pump | Italian brand or American brand | |
Hydraulic Motor | Italian brand or American brand | |
Gear Box | Italian brand or American brand | |
DIMENSIONS | ||
Tare Weight | 12300kg | |
Overall Length | 11000mm | |
Overall Width | 2490mm | |
SPECIFICATION | ||
Chassis | Skeletal Chassis with special designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Middle Flange 6mm,height 500mm; Bottom Flange 16mm,width 140mm. | |
Axle | 3 axles of Germany design 13 ton | |
Brand Name: BPW/FUWA | ||
Suspension | Germany design heavy duty mechanical suspension | |
Leaf Spring | 13 pieces leaf spring | |
King Pin | JOST brand 3.5” Bolt-in King Pin | |
Landing Gear | JOST brand Two-speed, manual operating, heavy duty landing gear | |
Wheel Rim | 9.0-22.5 wheel rim | |
Tyre | 12R22.5 tubeless tire, in total 13 PCS including one spare tire; 12.00R20/315/80R22.5 are optional | |
Spare Tire | One set of spare tire including 1 carriers | |
Braking System | WABCO RE4 relay valve; T30/30+T30 Spring brake chamber; 40L air tanks | |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint | |
Accessories | One standard tool box | |
Tank and Key accessary | ||
Capacity | 16CBM | |
Engine | American brand Cummins | |
Hydraulic Pump | Italian brand or American brand | |
Hydraulic Motor | Italian brand or American brand | |
Gear Box | Italian brand or American brand | |
