ZZ5707S3640AJ
SINOTRUK HOWO
8704
Specifications
Cabin | Driving type 6x4, HW7D cabin | |
Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 8400 x 3350 x 4200 |
Wheel base (mm) | 3600+1500 | |
Weight in KGS | Tare Weight | 29300 |
payload | 70000 | |
Front axles loading capacity | 1 x 18000 | |
Rear axles loading capacity | 2 x 36000 | |
Max. driving speed（km/h） | 50 | |
Engine | Brand | Sinotruk |
Model | WD615.47T2 | |
Type | 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
Horse Power（HP) | 371HP | |
Emission standard | Euro Ⅱ | |
Gearbox | HW21712, 12 Forwards gear & 2 reverse gear, double oil pump | |
Clutch | Reinforced diaphragm clutch, diameter 430mm | |
Steering Gear | ZF 8118, power steering, hydraulic steering with power assistance | |
Fuel tank (L) | 500L | |
Tire | 14.00-25 tyre, in total 11 pieces with one spare tire | |
Brakes | Service brake: dual circuit compressed air brake Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake | |
Bin size | 5500*3100*1800 mm, side is 14 mm, bottom is 16 mm | |
Hydraulic system | Front position, HYVA cylinder | |
