| Quantity: | |
|---|---|
Cabin | HW 76 cab, with one bed and air condition, 70°hydraulically tillable to the front as attached photo for ref. | |
Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 9800×2500×3200 |
Wheel base (mm) | 4325+1350 | |
Wheel track (front/rear) (mm) | 2022/1830/1830 | |
Approach/Departure angle(°) | 14.5/15 | |
Weight in KGS | Tare Weight | 12400 |
payload | 25000 | |
Front axles loading capacity | 1x7000 | |
Rear axles loading capacity | 2x16000 | |
Max. driving speed（km/h） | 102 | |
Engine | Brand | Sinotruk |
Model | WD615.69 | |
Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
Horse Power（HP) | 336 | |
Emission standard | Euro Ⅱ | |
Gearbox | HW19710,10-speed forward and 2 reverse gear | |
Steering | BOSCH, power steering, hydraulic steering with power assistance | |
Clutch | Reinforced diaphragm clutch, diameter 430mm | |
Fuel tank (L) | 400 | |
Tire | 12R22.5 tubeless tyre 11 pcs including one spare tire | |
Tank specification | 20,000 Liters Equipped with front(rear,side)sprinkler. Equipped with pump Equipped with fire valve,water valve,and filter gauze | |
Cabin | HW 76 cab, with one bed and air condition, 70°hydraulically tillable to the front as attached photo for ref. | |
Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 9800×2500×3200 |
Wheel base (mm) | 4325+1350 | |
Wheel track (front/rear) (mm) | 2022/1830/1830 | |
Approach/Departure angle(°) | 14.5/15 | |
Weight in KGS | Tare Weight | 12400 |
payload | 25000 | |
Front axles loading capacity | 1x7000 | |
Rear axles loading capacity | 2x16000 | |
Max. driving speed（km/h） | 102 | |
Engine | Brand | Sinotruk |
Model | WD615.69 | |
Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
Horse Power（HP) | 336 | |
Emission standard | Euro Ⅱ | |
Gearbox | HW19710,10-speed forward and 2 reverse gear | |
Steering | BOSCH, power steering, hydraulic steering with power assistance | |
Clutch | Reinforced diaphragm clutch, diameter 430mm | |
Fuel tank (L) | 400 | |
Tire | 12R22.5 tubeless tyre 11 pcs including one spare tire | |
Tank specification | 20,000 Liters Equipped with front(rear,side)sprinkler. Equipped with pump Equipped with fire valve,water valve,and filter gauze | |
