SINOTRUK HOWO LOG Transportation Truck

The LOG truck is used for wood transportation
Chassis: HOWO Tractor or dump truck chassis

Availability:
Quantity:
  • ZZ4257S3241

SINOTRUK HOWO  LOG Transportation Truck

IMG_20181130_113751


Specifications
Cabin Driving type 6x4      LHD
HOWO 76 new cabin,
with one bed, air condition, high steel bumper,70°hydraulically tillable to the front as attached photo for ref.
Weight in KGS Front axles loading capacity 1x9000
Rear axles loading capacity 2x16000
Max. driving speed(km/h) 102
Engine Brand SINOTRUK
Model WD615.47
Type 4-stroke direct injection ,  6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Horse Power(HP) 371HP
Emission standard Euro Ⅱ
Gearbox HW19710, 10 Forwards gear & 2 reverse gear
Clutch Reinforced diaphragm clutch, diameter 430mm
Steering Gear ZF 8098,power steering, hydraulic steering with power assistance
Fuel tank (L) 400
Tire 12R22.5 tubeless tire, 11 pcs including one spare
Brakes Service brake: dual circuit compressed air brake
Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust brake
Specifications of trailer
I Beam & Chassis Heavy duty and extra durability designed I beam, welded by automatic Submerged-Arc processes.
Axle FUWA brand, 2 axles, 16 ton loading capacity per axle.
Suspension 32T single point suspension
Wheel Rim 9.0-22.5 wheel rim 13 pieces
Tire 12.00R22.5 radial steel tire with one spare tire. 9 pieces
Spare Tire One set of spare tire with a carrier
Braking System WABCO RE 4 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks
Painting Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint









WARRANTY

1. Twelve months quality guarantee for three key parts axles, engine and transmission or within 100,000km, which comes first for trucks. 6 months quality guarantee for three key parts axles, beam and landing gear or within 50,000km, which comes first for trailers.


2. Other spare part could be supplied by OEM at cost prices.


3. Regularly callback to know the vehicle's working status.


4. The overseas engineers are always ready to deal with unexpected needs.

1. MOQ: 1 unit


2. Optional payment terms: T/T or L/C
  T/T: 30% deposit by T/T, 70% balance should be paid before shippment.
  L/C: 30% payment advance, 70% L/C at sight.


3. Parts of famous brand can be adopted by your requirement, such as WABCO, JOST, BPW, FUWA.


4. Delivery time: Within15 workdays after receiving 30% deposit of T/T
