ZZ1167M4617D3
SINOTRUK HOWO
HOWO Brand New 4X2 Heavy Loading Road Paving Machinery
Specifications
| Cabin | HW 76 standard cab, with one bed and Air Condition, 70°hydraulically tillable to the front as attached photo for ref. | |
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 9000×2500×3250 |
| Wheel base (mm) | 4600 | |
| Wheel track (front/rear) (mm) | 2022/1830 | |
| Approach/Departure angle(°) | 16/10.5 | |
| Weight in KGS | Tare Weight | 6910 |
| Front axles loading capacity | 1x7000 | |
| Rear axles loading capacity | 1x16000 | |
| Max. driving speed（km/h） | 102 | |
| Engine | Brand | SINOTRUK |
| Model | WD615.47 | |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Horse Power（HP) | 371 | |
| Emission standard | Euro Ⅱ | |
| Gearbox | HW13710, 10 Forwards gear & 2 reverse gear | |
| Clutch | Reinforced diaphragm clutch, diameter 430mm | |
| Steering Gear | ZF brand, power steering, hydraulic steering with power assistance | |
| Fuel tank (L) | 400 | |
| Tire | 12R22.5 tubeless tyre 7 pcs including one spare tire | |
| Brakes | Service brake: dual circuit compressed air brake | |
| Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels | ||
| Auxiliary brake: engine exhaust brake | ||
| Tank | Stainless steel tank, 10,000liters. | |
| Hydraulic system | Proportional valve , automatic reversing valve and overflow valve, asphalt pump hydraulic drive motor, hydraulic pump or engine power take-off | |
| Control system | Intelligent computer control in cabin. | |
| Spray Width | 4.5meters. | |
