Sinotruk HOWO 6x4 LPG Gas Tank Bobtail Truck

Basic Info:
Color:Optional     Logo:Can be customized as your request
Origin:China        Package:Nude
Factory price with trusted quality
Availability:
Quantity:
  • ZZ1317N3867
  • SINOTRUK HOWO

SINOTRUK HOWO 6x4 LPG Gas Tank Bobtail Truck

bobtail2

Specifications:

HOWO 6X4 LPG Fuel truck


Cabin

Driving type 6x4      LHD

HW76 cabin with one sleeper and A/C


Vehicle Main Dimensions

Overall dimensions (L x W x H)mm

12000×2500×3600

Wheel base  (mm)

1800+4600+1350




Weight in KGS

Tare Weight

17000

payload

15000

Front axles loading capacity

1x7000

Rear axles loading capacity

2x16000

Max. driving speed(km/h)


90






Engine

Brand

SINOTRUK

Model

WD615.87


Type

4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charged and inter-cooled
Horse Power(HP) 290
Max Torque (N.m) 1160
Emission standard Euro II
Gearbox HW13710, 10-speed forward and 2 reverse gear,
Steering power steering, hydraulic steering with power assistance
Tire 12R22.5 tubeless tyre with one spare




Tank Spec

1.Volume: 35000 liters LPG tank body made of high tensile steel, thickness 12 mm;

2.Filling coefficient: 0.42

3. Filling Medium: Propane

4.Working pressure: 1.61 Mpa, Test Pressure: 2.66 Mpa

5. With emergency cut valve, thermometer, pressure-gauge, liquidometer, Fast coupling, safety valve, tool box, valve box

6.Pump and flow meter equipped


60b40
